Maximum diameter of end mill

mm

25

Spindle hole taper

ISO40

Distance from the end face of the spindle to the workbench

mm

100-480

Spindle speed range

r.p.m

35-1600

Angle of return of end milling head

360°

Work surface size

mm

1250X320

Maximum stroke of the workbench

mm

600X200

From the center of the spindle to the surface of the column

mm

0-500

Main drive motor power

kw

2.2

Feed motor power

w

750

Lifting motor power

w

750

Cooling pump motor power

w

40

Machine tool dimensions

mm

1700X1560X1730

Net weight/gross weight

kg

1320/1420
